There Are No Better Protected Displays Than Our IP 66 High Brightness Displays. With An Entirely Enclosed Design, The IP 66 High Brightness Display Is The Answer To Any Commercial Display Need In A Non-Forgiving Environment.
TECH SPECS
Panel
Size
55 inch
Active Display Area ( H x V mm )
1209.6 x 680.4
Resolution
1920 x 1080
Aspect Ratio
16 : 9
Brightness
2500 nits
Backlight Adjustment
Automatic ( Ambient Light Sensor )
Viewing Angle
178° / 178°
Backlight Configuration
Direct LED
Operation Life Cycle-mtbf(hours)
50,000
Mechanical
Dimensions ( W x H x D )
779 x 1955 x 120 mm
Net Weight ( kg )
TBD kg
Enclosure Material
Galvanized Steel + Aluminum
Finishing
Zinc Powder Coating + Fine Grain Powder Coating
Colour
Black ( Ral 9005)
Glass
Tempered Glass, Back Painted Pantone Black C
Sounds
N / A
Power
AC Input
110 VAC - 220 VAC,50 / 60Hz
Power Consumption
310 w
Environmental
IP Rating
IP66
Operating Environment
Fully Outdoor
Operating Humidity
5% ~ 98%
Operating Altitude
≤ 2000m
Operating Temp.
-20℃ ~+45℃ ( Outdoor , direct sunlight 1200W/m² ) / -20℃ ~+50℃ ( Outdoor , direct sunlight 850W/m² )
