KWO37-66
Outdoor Digital Advertising Signage
37 Inch LCD Screen
High Brightness: 2500Nits
IP66-Fully Enclosed System
Maintenance Free
Android OS / Windows OS / TV Board
1920x540
Features
There Are No Better Protected Displays Than Our IP 66 High Brightness Displays.
With An Entirely Enclosed Design, The IP 66 High Brightness Display Is The Answer
To Any Commercial Display Need In A Non-Forgiving Environment.
Outdoor Digital Signage
High Brightness: 2500 nits (Truly Sunlight Readable)
IP66 (Fully Enclosed System)
Maintenance Free
No Fans
No Vents
No Filters
Applications
Floor Standing Design
Ceiling Hanging Design
Wall Mounted Design
All in One Solutions
High Brightness LCD Screen
PC / Android / TV Board
DIY Outer Casing
Digital Menu Board Kiosks
One Column
Two Columns
Three Columns
TECH SPECS
| Model | KWO37-66 |
| Size | 37 |
| Panel | |
| Panel Size (inch) | 37 |
| LCD Manufacturer | LG / Samsung / AUO / Keewin / BOE |
| Active Display Area (h x w mm) | 899 x 253 |
| Resolution (pixel) | 1920 x 540 |
| Aspect Ratio | 16 : 4.5 |
| Brightness (nits) | 2500 |
| Contrast Ratio | 4000 : 1 |
| Grey to Grey Response Time (ms) | 16 ms |
| Viewing Angle (H/V) | 178°/178° |
| Backlight Configuration | LED light |
| Operational Life Cycle-mtbf (hours) | 50000 |
| Power | |
| Input Voltage | AC220 / 110V ± 10%, 50 / 60 HZ |
| Max Power Consumption (w) | 130 |
| Enclosure Material | |
| IP Rating | IP66 |
| Enclosure Material | Galvanized steel + zinc powder coating + fine grain powder triple coating |
| Glass Type | Tempered glass with AR coating |
| Glass Characteristics | Transmissivity > 93%, Reflectivity < 2% |
| Unit Dimension (w x h x d mm) | 350 x 996 x 91.5 |
| Bezel Width (mm) | 48.5 |
| Weight (kg) | 40 |
| Environment | |
| Operating Environment | Outdoor |
| Operating Temp. | -20℃ ～+50℃ |
| Operating Humidity | 5% ~ 98% |
| Operating Altitude (m) | ≤ 2000 |
| Media & Connectivity | |
| Option | Windows / Android / TV Board |
| Wifi | |
| 4G /3G | |
| Touch Screen | |
